Helical and Worm Gears for Linear Operators

Our helical gears achieve AGMA 2000 Class 10 on non-heat-treated (hobbed/shaped) gears and AGMA 2000 Class 13 on heat-treated, profile-ground gears. Worm gears and worm wheels are manufactured using precision hobbing processes, with worms produced from carburized, hardened, and ground steel for maximum wear resistance.

Worm wheels are typically manufactured from CDA 954 aluminum bronze or CDA 932 bronze, with steel available as an option for specific applications. Mating worms are made from carburizing-grade steel, then carburized, hardened, and ground to ensure durability and precise meshing in high-torque linear operator systems.

Yes. Carnes-Miller Gear offers reverse engineering services for both helical gears and worm gears when original OEM drawings or specifications are unavailable. By analyzing a provided sample, our team defines all critical data and tolerances to manufacture a precise replacement, minimizing downtime for your equipment.

Carnes-Miller Gear can manufacture helical gears with helix angles up to +/- 45 degrees. This broad range accommodates crown hobbing and taper hobbing configurations, enabling smooth, quiet power transmission with reduced axial thrust in linear operator drives and industrial machinery across diverse sectors.

Our gears are used across industrial machinery, mining equipment, transportation systems, construction, agricultural machinery, rail, aerospace (grind teeth only), defense, and medical equipment applications. Carnes-Miller Gear also supports OEM manufacturers needing custom gears and aftermarket replacement parts for obsolete equipment.

Both options are available. Carnes-Miller Gear offers full turn-key manufacturing — machining gear blanks and shafts in-house complete to customer drawings — or cut teeth only services on customer-supplied blanks. Precision grinding is available separately for gears requiring AGMA Class 13 surface finish and tolerance levels.
