Planetary Gearboxes

Planetary gearboxes, also known as epicyclic gear systems, feature ring gears, sun gears, and planet gears working in precise harmony. Our precision-manufactured planetary components support industrial machinery, mining equipment, transportation systems, and agricultural applications. With over 50 years of manufacturing expertise, we deliver AGMA 10-13 quality ratings and custom solutions for demanding transmission requirements.

Our Range of Products
Planetary Gears

Planetary Gears

  • Ring gears to 10" pitch diameter
  • Sun & planet gear compatibility
  • Face width capacity to 5 inches
Ring Gears

Ring Gears

  • AGMA 10-13 quality ratings
  • 10" max pitch diameter capacity
  • Turn-key manufacturing services
Custom Gears

Custom Gears

  • 50 years manufacturing experience
  • Reverse engineering capability
  • In-house grinding to 400mm
Precision Gear Manufacturing Services

Precision Gear Manufacturing Services

  • Precision grinding to 400mm
  • Custom lead & profile mods
  • AGMA 13 quality assurance

Frequently Asked Questions

What is a planetary gearbox?

A planetary gearbox is an epicyclic gear system featuring a central sun gear, surrounding planet gears, and an outer ring gear working together to transmit torque efficiently.

What are the advantages of a planetary gearbox?

Where would you use a planetary gearbox?

What quality standards do your planetary gears meet?

Can you manufacture custom planetary gear configurations?

What is the maximum size planetary gear you can produce?

Do you offer reverse engineering for obsolete planetary gears?

Didn't find what you're looking for?

Talk to our experts for custom solutions and tailored guidance.

Industries We Serve

Mining

Mining

Heavy-duty planetary gears for conveyors, crushers, and drilling equipment requiring robust torque transmission.

Industrial Manufacturing

Industrial Manufacturing

Precision planetary systems for automated machinery, robotics, and production equipment demanding reliability.

Transportation

Transportation

Epicyclic gears for vehicle transmissions and drive systems requiring compact, efficient power transfer solutions.

Agriculture

Agriculture

Durable planetary gear components for tractors, harvesters, and farm equipment operating in harsh conditions.

Didn't find what you're looking for?

Talk to our experts for custom solutions and tailored guidance.
